Dynamatic Gear Pump Features:

  • Worldwide sales and service capabilities from one of the industry leaders

  • Proven reliability with over 45 years of experience in gear product design for mobile and industrial applications

  • System pressures to 280 Bar and speeds to 4000 rpm allow high performance in system design

  • Low cost design and manufacturing for the requirements of fixed displacement systems

Dynamatic Aluminium Gear Pump Range:

SP2/250 Series Gear Pumps Technical Data

Frame Size

05

06

08

10

12

16

18

20

23

25

28

Displacement

cc/rev

5.1

6.4

8.3

10.3

12.8

16.1

18.5

20.5

23.0

25.7

28.7

Max Pressure

Bar

250

250

250

250

250

230

230

230

210

185

165

Peak Pressure

Bar

275

275

275

275

275

250

250

250

225

200

180

Maximum Speed

RPM

3600

3600

3600

3600

3600

3600

3000

2750

2750

2750

2750



SP2.5/250 Series Gear Pumps Technical Data

Frame Size

20

22.4

25

28

31.5

35.5

40

45

Displacement

cc/rev

20.00

22.00

25.00

28.00

31.50

35.50

40.00

45.00

Max Pressure

Bar

250

250

250

250

250

250

220

200

Peak Pressure

Bar

275

275

275

275

275

275

  245

225

Maximum Speed

RPM



3000

3000

2800

2800

2800

2700

2500

2500



Dynamatic Cast Iron Gear Pump Range:

2.5 C.I. Series Gear Pumps Technical Data

Frame Size

14

18

22

26

29

33

38

41

44

Displacement

cc/rev

14

18

22

26

29

33

38

41

44

Max Pressure

Bar

275

275

275

275

275

255

225

205

185

Peak Pressure

Bar

300

300

300

300

300

280

250

230

210

Maximum Speed

RPM

3000

3000

3000

3000

3000

2800

2700

2700

2600



3.5 C.I. Series Gear Pumps Technical Data

Frame Size

26

29

33

38

41

44

48

56

63

Displacement

cc/rev

26

29

33

38

41

44

48

56

63

Max Pressure

Bar

275

275

275

275

250

275

275

245

215

Peak Pressure

Bar

285

285

285

285

260

285

285

255

225

Maximum Speed

RPM

2600

2600

2600

2600

2600

2600

2600

2600

2600


For multiple pump combinations please consult Dynamatics Sales/Applications department
.

The SP2.5/250 Series pump is offered with flow dividers that include the following options:

  • STD PFD - no RV

  • STD PFD - with RV

  • Load Sense PFD - Static

  • Load Sense PFD - Dynamic

Dynamatic Symbolic Schematic of PED with RV Option
